IFT  +TENS+ MS features

Ø  125 pre-program with protocols and Manual operating system ( 70 pre-program for ift ,30 pre-program for TENS , and  25 program for  MS )

Ø  Therapy Mode: IFT  ( 4 P , 2 P , 4 PV , Russian current) , TENS (Cont. ,Burst,  PWM  & Sweep ), MS (Galvanic, Int. Galvanic, Faradic, and Surged Faradic )

Ø  Multi vector scan : 2PL Linear  45 °,4 PL Linear 90 °

Ø  Spectrum pattern :  Triangular , Trapezoidal ,Square

Ø  Beat frq : 0- 150cont  , 0-10 scan  , 80-150 scan  &  0-150 scan for ift

Ø  Carrier frq  : 2 khz &  4 khz, 2.5 khz For ift

Ø  Low Frq : 2,40, 100,150  for tens

Ø  Treatment Duration:-     1 - 30 min in 1 min increments

Alarms  Audio Alarm at the end of Treatment with auto cut off

Ø  Micro computer controlled based  with backlight 16×2 alpha numeric LCD Display of timer ,therapy mode ,carrier frequency makes, Separate  display  for both channel out put amplitude, Beat frq ,TENS & MS  therapy mode

Ø  Amplitude balance controlled :-  To equilise 2 channel current

Ø  Amplitude controlled :- 0 to 99 ma (peak to peak varible )

Ultrasound features

Ø  Therapy mode : Continuous  and  Pulsed

Ø  Continuous Mode Output :-    3.5 w/cm2 maximum

Ø  Pulsed Mode Output :-          2.2 w/cm2 maximum

Ø  Output Frequency:-     1  MHz ± 2%

Ø  Pulse ratio :-    1:2, 1:4, 1:7, & 2:2

Ø  Display : seven segment digital display

TECHNICAL SPECIFICATIONS

Ø  Micro computer controlled based  with backlight 16×2 alpha numeric LCD Display of timer ,therapy mode ,carrier frequency makes, Separate  display  for both channel out put amplitude, Beat frq ,TENS and MS  therapy mode and digital display for timer and output

Ø  Treatment Duration:-     1 - 60 min in 1 min increments

Audio Alarm at the end of therapy with auto cut off

Ø  Input Power:- 220  -240 V ~; 50/60 Hz

Ø  Weight :- 5.5  kg  aprox

Ø  Brand : physio combination 4 in 1

STANDARD ACCESSORIES

Ø  Main Unit : 01 No.

Ø  Ift carbon electrode : 1 pair red  and  1pair blue

Ø  Ift  out put lead :  2 red wire & 2 black wire

Ø  Fixing elastic belts: 02 set. ( each set three different size of belt  small, medium  and  large )

Ø  Pencil probe :1 no with two pointed ball for different size

Ø  Ultrasonic applicator : 1 no

Ø  Ultrasonic out put cable : 1 no

Ø  Carry bag : 1 no

Ø  Power cable: 01 No.
