Tens feactures

Ø  Therapy mode : Cont ,Burst, , PWM  & Sweep

Ø  Four channels , isolated between channels

Ø  Amplitude current : 0-100mA peak to peak into 500 ohm load each Channel

Ø  Frq : Adjustable 2,20,40, 80,130

Ø  Patient safety should be available with no output while intensity is high by switching on the machine.

Ø  Display : seven segment digital display for timer

Ø  LED display  eachchannel for pulse mode and pulse frequency

Ultrasoud  feactures

Ø  Therapy mode : Continuous  & Pulsed

Ø  Continuous Mode Output :-        3.5 w/cm2 maximum

Ø  Pulsed Mode Output :-          2.2 w/cm2 maximum

Ø  Output Frequency:-        1  MHz ± 2%

Ø  Pulse ratio :-       1:2, 1:4, 1:7, & 2:2

TECHNICAL SPECIFICATIONS

Ø  Display : seven segment digital display for timer & output

Ø  Treatment Duration:-     1 - 60 min in 1 min increments

Audio Alarm at the end of therapy with auto cut off

Ø  Compact desizn for home visit purpase

Ø  Input Power:- 220  -240 V ~; 50/60 Hz

Ø  Weight :-2.5 kg  aprox

Ø  Brand : physio combination 4TU

STANDARD ACCESSORIES

Ø  Main Unit : 01 No.

Ø  Tens carbon electrode : 8 roun electrode 4 cm dia

Ø  Tens out put lead : 4 no.

Ø  Fixing elastic belts: 02 set. ( each set three different size of belt  small, medium  and  large )

Ø  Us applicator – 01 No

Ø  Us applicator out put cable : 01 No

Ø  Instruction Manual :01 No

Ø  Power cable provided for different countries: 01 No.

Ø  Carry bag : 1 No

Ø  Jel bottale : 1No
